Lunt Backing Plate and Focuser for LS152THa
Rear Plate And Focuser For LS152THa Scopes
The LS152T/BP&F is the backing plate and two inch Crayford focuser assembly for the Lunt LS152THa, the 152 mm hydrogen alpha solar telescope. The backing plate is the rear interface of the optical tube and the focuser mounts to it, so the two are supplied together as one part.
Its purpose is conversion. Remove the rear pressure tuned etalon section from the LS152THa and fit this plate and focuser in its place, and the same optical tube becomes a night time refractor. The Crayford is dual speed and takes two inch accessories, replacing the rack and pinion focuser the scope ships with.
This is a mechanical assembly with no filtering function. The LS152THa is a dedicated solar telescope whose safety comes from its own etalon and blocking filter system, and this plate carries no solar filtration of its own. With the etalon section removed the tube is a night telescope only, so never aim it at the Sun without correct certified solar filtration fitted and verified.
Key Features
- Matched Assembly - backing plate and focuser supplied together as the rear end unit for the LS152THa.
- Single Telescope Fit - specified for the Lunt LS152THa 152 mm hydrogen alpha solar telescope rather than the wider range.
- Rear Interface - the plate forms the mounting face at the back of the optical tube that the focuser bolts to.
- Dual Speed Crayford - a two inch Crayford style focuser with dual speed fine focus in place of the stock rack and pinion.
- Mechanical Only - no optical elements and no filtering role, so it does not alter the telescope's solar safety chain.
- Day To Night Conversion - swaps in where the pressure tuned etalon section comes out, turning the solar scope into a night time refractor.
| Specifications | |
|---|---|
| Type | Backing plate and focuser assembly for a dedicated solar telescope |
| Model / SKU | LS152T/BP&F |
| Telescope fit | Lunt LS152THa, 152 mm hydrogen alpha solar telescope |
| Assembly contents | backing plate and focuser supplied together |
| Focuser type | Two inch Crayford style, dual speed |
| Focuser travel | Not published |
| Drawtube size | 2 inch |
| Mounting thread | Not published |
| Fine focus ratio | Dual speed fine focus, exact ratio not published |
| Load capacity | Not published |
| Materials and finish | Not published |
| Motor focus compatibility | Not published |
| Solar safety | Replaces the rear pressure tuned etalon section, which converts the telescope for night time use; it is a mechanical part only and carries no solar filtration of its own |
| Shipping weight | Not published |
| Warranty | 5 years from date of purchase, original purchaser, manufacturing and workmanship defects |
